TS-TR series thermal resistance signal isolator, accepts the thermal resistance signal from the field, and outputs the standard current/voltage signal to the control room, PLC, display instrument and DCS, etc. Through the miniUSB interface to connect the PC host computer to the input signal division number, range range, alarm output value; Output range, type, etc. RS485 communication function (need to be customized) The product needs independent power supply, using DIN35mm standard rail independent installation mode (optional bus power supply function); The input, output and power supply are isolated from each other.

Product parameter

Product parameter

Input end

Input signal: thermal resistance, resistor, potentiometer and other resistance signals allow line resistance ≤50Ω(three-wire system)

Overlimit alarm: the input is lower than the lower limit of the range, the output current is about 3.8mA(current output), the input is higher than the upper limit of the range, the output current is about 20.5mA(current output)

Line break alarm: When the input line is broken, the output current is about 22mA(current output)

Output end

Output signal: Current signal :0-20mA; Voltage signal :0-10V(current voltage signal type and range can be set by PC)

Digital signal :RS485(optional, not included by default)

Output load resistance :RL≤400Ω(output current signal) RL≥10KΩ(output voltage signal)

Basic parameter

Number of channels: 1 in 1 out, 1 in 2 out, 2 in 2 out

Power supply :DC24V, voltage range :DC18~32V

Consumption current :≤80mA(two in two out, 24V power supply, 20mA output)

Basic accuracy :±0.1%F.S or ±0.2%F.S(20℃) subject to physical labeling.

Temperature drift :±0.01%F.S/℃(-20℃~+55℃)

Response time :≤1S(0-90%)(TYP)

Insulation strength :1500V AC/1min(between input, output and power supply)

Insulation resistance :≥100MΩ(input, output, power supply)

Operating temperature range :-20~+55℃(no condensation, no icing)

Electromagnetic compatibility: according to GB/T18268.1(IEC61326-1)

Applicable field equipment: thermal resistor, resistor, potentiometer

Wiring diagram

Wiring diagram

Note :

1, wire heating resistor or potentiometer signal input, terminal 9,10 (TS-TR2XX); 7,8 (TS-TR5XX); 11,12(TS-TR5XX) Must be short-circuited. Two-wire connections do not eliminate wire resistance, and errors increase.

2. When the three-wire heating resistor or potentiometer signal is input, the resistance value of the three wires should be equal as far as possible.

3, the bus power supply and RS485 output function is optional, if necessary, please specify and purchase the bus power supply module when ordering. TS-TR5XX No 485 output function.
